Metal Fabrication Services

CUTTING

Laser

  • 2 Trumpf Trulaser 5040 with Stopa storage & retrieval: mild steel to 1.250”, stainless to 1.000”, aluminum to 0.750”
  • Trumpf L1030: mild steel to 0.625”, stainless to 0.250”, aluminum to 0.188”
  • Mitsubishi ML 3015LV with FMS Tower storage & retrieval: mild steel to 1.000”, stainless to 0.500”, aluminum to 0.375”
  • Mitsubishi NX with FMS Tower storage & retrieval: mild steel to 1.250”, stainless to 0.750”, aluminum to 0.750”

Waterjet

  • Mitsubishi Suprema: all materials up to 6.0”

Saw

  • Up to 18” x 20” rectangular, and 18” round

Punch Press

  • Weidemann: 60-ton 0.500” material thickness in steel
  • Trumpf: 25-ton 0.312” material thickness in steel

FORMING

Press Brake

  • Trumpf V850: 90-ton, 84” bed
  • Trumpf V320: 350-ton, 156” bed
  • Cincinnati 350T: 350-ton, 168” bed
  • Cincinnati 90T: 90-ton, 120” bed
  • European and standard tooling

Roller

  • Roundo Pass 310: 4-roll, 10’ x 0.625”
  • Americor: 4-roll, 5’ x 0.25”

MACHINING

  • Haas GR-510 Gantry Router: working range 121” x 61” x 11” (X-Y-Z)
  • Milltronics Partner 7-H VMC: working range 45” x 30” x 20” (X-Y-Z)
  • Okuma Genos M560 VMC: working range 51” x 22” x 18” (X-Y-Z)

WELDING

The welding team at Jones Metal has the expertise to work with a comprehensive range of materials to provide products that meet your precise specifications. Jones Metal has developed an extensive in-house training program to ensure that welders are continually improving their skills and acquiring the highest levels of AWS standards and certifications. The result is a team of experienced welders focused on high-quality production processes, including robotic welding.

Capabilities

  • PRI Lincoln System 55 Robotic Welder: 60” swing, 108” bed length, 1600# capacity
  • Genesis Versa 2L Robotic Welder: 60” swing, 144” bed length, 5000# capacity
  • MIG
  • TIG (with cold feed capability)
  • Resistance

Certifications

  • ASME Section IX
  • NAVSEA S9074-AQ-GIB-010/248
  • MIL-STD 248D
  • MIL-STD 1595A
  • AWS D1.6
  • AWS D1.1
  • AWS D17.1
  • AWS B2.1
  • AWS Robotic Welding Certification Standards (other standards on request)
